Steel Picket Fencing

Steel picket fencing is constructed of steel for maximum longevity and strength, and crafted to look like traditional wrought iron fence. While aluminum fence has become popular for property enclosures due to its corrosion resistance and weight, steel fencing is a stronger alternative. With a chemically bonded powder coated finish and zinc phosphate undercoat, a steel fence panel can outlast an aluminum panel even in harsh conditions. Steel construction allows for longer panels without sag under weight or stress, which also allows for fewer post holes and less labor!

Post enlarged by 25% from 2 to 2-1/2 square
Post reinforced by internal rib to resist bending
Rail enlarged by 25% from 1 to 1-1/4 high
Rail reinforced internally to resist side impact
Picket enlarged by 25% from 5/8 to 3/4 square
Holes to mount rail eliminated from post design
Replaced by stronger exterior bracket

Standard color is black. Other powder coat colors are available as special order.



Technical Info:
PICKET:
5/8" x 5/8" x. 050" wall thickness
1" x 5/8" x. 050" wall thickness
1" x 1" x. 065" wall thickness

RAIL:
1" x 1" x. 055" top wall, 080" side wall
1 1/2" x 1 1/8" x. 060" top wall, 070" side wall
1 5/8" x 1 5/8" x. 070" top wall, 100" side wall

POST:
2" x 2" x. 060" wall
2 1/2" x 2 1/2" x. 060" wall, 100" power corner
2 1/2" x 2 1/2" x. 075" wall

GATE POST:
2" x 2" x. 125" wall
2 1/2" x 2 1/2" x. 060" wall, 100" power corner
4" x 4" x. 125" wall
6" x 6" x. 188" wall

SPACING:
3 13/16" between pickets
1 39/64" (styles Higaleah and Innsbruck)
3 31/32" between pickets
3 31/32" between pickets

INSTALLED CENTERS:
72 3/4" on center 2" posts
100 13/16" on center 2 1/2" posts (2 rail Elba 71" on center 2 1/2" posts)
71" on center 2 1/2" posts

HEIGHTS:
36", 42", 48", 54", 60", 72"
48", 54", 60", 72"
48", 60", 72", 84", 96"

COLORS:
Black, White, Bronze, Hunter Green

HORIZONTAL RAILS:
3 on 36", 42", 48", 54", 60"; 4 on 72"
3 on 48", 54", 60"; 4 on 72"
(2 on 48" Guardian Elba)
3 on 48", 60", 72"; 4 on 84", 96"

ALLOY:
6063-T5 on pickets; 6061-T6 on posts and rails

STRENGTH:
Over 350 lbs
Over 350 lbs
Over 1, 100 lbs
